Description | Capacity (Ton) | 1.5 Ton |
General Parameter | Type | DC Inverter |
Cooling Capacity (BTU) | 19000 | |
Heating Capacity (BTU) | 19500 | |
Air Circulation (m3/h) | 850 | |
Power input (W) Cooling | 410 – 2200 | |
Power Input (W) Heating | 420 – 2250 | |
Running Current (A) Cooling | 2.3 -10.2 | |
Running Current (A) Heating | 2.4 -10.3 | |
Power Supply (PhN/Hz) | 1/220/50 | |
Appearance | Color | White |
Parts | Refrigerant | R-32 |
Refrigerant Pipe | Liq Side: 6mm. Gas side: 12mm | |
Warranty | Warranty | 1 year Parts, 5 Years compressor |
Dimensions | Indoor Net Dimension W/D/H | 900/310/215 |
Indoor Packing Dimension W/D/H | 982/396/302 | |
Outdoor Net Dimension W/D/H | 820/300/610 | |
Outdoor Packing Dimension W/D/H | 955/418/670 | |
Indoor Gross weight (Kg) | 15.5 | |
Indoor Net weight (Kg) | 12.5 | |
Outdoor Gross Weight (Kg) | 37 | |
Outdoor Net Weight (Kg) | 34 | |
Noise | Indoor Noise [db(A)] (Hi/Mid/Lo/So) | 47/43/39 |
Outdoor Noise (db(A)] | 55 | |
Compatibility | UPS Enabled with additional Device | Enabled with UPS Device |
WiFi | Optional |
Description | Capacity (Ton) | 1 Ton | 1.5 Ton |
General Parameter | Type | DC Inverter | DC Inverter |
Cooling Capacity (BTU) | 13000 | 19000 | |
Heating Capacity (BTU) | 13500 | 19500 | |
Air Circulation (m3/h) | 700 | 1100 | |
Power input (W) Cooling | 450 – 1410 | 410 – 2200 | |
Power Input (W) Heating | 450 – 1450 | 420 – 2250 | |
Running Current (A) Cooling | 2.6 – 6.6 | 2.3 -10.2 | |
Running Current (A) Heating | 2.6 – 6.7 | 2.4 -10.3 | |
Power Supply (PhN/Hz) | 1/220/50 | 1/220/50 | |
Appearance | Color | White | White |
Parts | Refrigerant | R-32 | R-32 |
Refrigerant Pipe | Liq Side: 6mm. Gas side: 9mm | Liq Side: 6mm. Gas side: 12mm | |
Warranty | Warranty | 1 year Parts. 5 Years compressor | 1 year Parts. 5 Years compressor |
Dimensions | Indoor Net Dimension W/D/H | 850/295/210 | 1015/325/225 |
Indoor Packing Dimension W/D/H | 952/389/283 | 1090/415/313 | |
Outdoor Net Dimension W/D/H | 700/245/535 | 820/300/610 | |
Outdoor Packing Dimension W/D/H | 845/320/593 | 955/418/670 | |
Indoor Gross weight (Kg) | 14.1 | 17.7 | |
Indoor Net weight (Kg) | 11.5 | 14.4 | |
Outdoor Gross Weight (Kg) | 29 | 37 | |
Outdoor Net Weight (Kg) | 26 | 34 | |
Noise | Indoor Noise klb(A)1(Hi/Mid/Lo/So) | 41/36/30 | 47/43/39 |
Outdoor Noise [db(A)] | 52 | 55 | |
Compatibility | UPS Enabled with additional Device | Enabled with UPS Device | Enabled with UPS Device |
Wifi | Wifi Available | Wifi Available |
Features:
Features:
Description | Capacity (Ton) | 1.5 Ton |
General Parameter | Type | DC Inverter |
Cooling Capacity (BTU) | 18000 | |
Heating Capacity (BTU) | 18000 | |
Air Circulation (m3/h) | 1100 | |
Power input (W) Cooling | 1452(450-2600) | |
Power Input (W) Heating | 1416 | |
Running Current (A) Cooling | 4.45 | |
Running Current (A) Heating | 6.89 | |
Power Supply (Ph/V/Hz) | 1,220~230,50 | |
Appearance | Color | White |
Parts | Refrigerant | R410a |
Refrigerant Pipe | Liq Side: 6mm, Gas side: 12mm | |
Warranty | Warranty | 1 year Parts, 10 Years compressor, 4 Year PCB |
Dimensions | Indoor Net Dimension W/D/H | 1050235/350 |
Indoor Packing Dimension W/D/H | 1120/324/435 | |
Outdoor Net Dimension W/D/H | 890/340/705 | |
Outdoor Packing Dimension W/D/H | 1046/460/780 | |
Indoor Gross weight (Kg) | 14.5 | |
Indoor Net weight (Kg) | 11.5 | |
Outdoor Gross Weight (Kg) | 47 | |
Outdoor Net Weight (Kg) | 24 | |
Noise | Indoor Noise[db(A)] (Hi/Mid/Lo/So): | 47/44/41 |
Outdoor Noise[db(A)]: | 55 | |
Compatibility | UPS Enabled with additional Device | NO |
WIFI Available | NO |
